NOTES:

Part #	Number on image	Usage Notes
405-200-720	2	Always supply serial number when ordering gearbox parts
411-160-702	42	Not Fitted in all markets

715 - 340 Stealth S1 FM - Drive & Cutting System

Stealth S1 FM 340

Grouped product items
No.	Product Name	Price
1	PTO Complete Driveshaft - 900mm - 540/1000rpm (Trimax Specification) 406-340-840 More Info >	£391.79
2	Gearbox - Standard Rotation - 540rpm i See notes section for usage notes on this part 405-200-720 More Info >	£644.30
3	Bolt 301-212-303 More Info >	£1.27
4	Washer - Spring M12 - Trimax Specification - 308-120-043 More Info >	£0.33
5	Washer - Heavy Flat 308-120-063 More Info >	£0.33
6	Pulley - Taper Lock 403-361-270 More Info >	£131.97
7	Bush - Taper Lock 402-060-680 More Info >	£43.76
8	Key 405-425-940 More Info >	£7.94
9	Cover 410-330-386 More Info >	£10.30
10	Washer - Flat M12 - Trimax Specification - 308-120-013 More Info >	£0.33
11	Decal - Instruction - Wing Lift PTO Warning Stealth 424-101-160 More Info >	£5.00
12	Vee Belt 404-040-830 More Info >	£22.91
13	Vee Belt 404-041-300 More Info >	£37.91
14	Bolt 301-212-453 More Info >	£1.64
16	Stud 403-330-443 More Info >	£1.43
17	Belt Retainer Guide 417-330-450 More Info >	£16.56
18	Nut - Half 307-212-023 More Info >	£1.01
19	Pulley - Idler 403-360-110 More Info >	£20.59
20	Bearing - 6301 DDU 12 x 37 x 12 - Trimax Specification - 401-021-900 More Info >	£10.30
21	Washer - Flat 108-071-413 More Info >	£1.22
22	Circlip/Snap Ring - Internal 204-820-371 More Info >	£1.40
24	Idler Tower Incl Base 403-330-423 More Info >	£55.89
25	Idler Tower Incl Base 403-330-424 More Info >	£53.82
26	Idler Tower Incl Base 403-330-432 More Info >	£39.97
27	Idler Tower Incl Base 403-330-442 More Info >	£49.52
28	Nut - Plain M12 - Trimax Specification - 307-212-013 More Info >	£0.80
29	Bolt 301-208-203 More Info >	£0.58
30	Bolt 301-208-403 More Info >	£1.01
31	Retainer Ring 402-060-450 More Info >	£6.66
32	Bush 402-060-320 More Info >	£20.19
33	Pulley 403-360-300 More Info >	£35.19
34	Spindle Assembly - Type 5a Ext 50mm 504-328-042 More Info >	£83.30
36	Cap Screw 303-212-505 More Info >	£2.01
37	Bolt 301-212-553 More Info >	£2.27
38	Nut - Binx 307-212-063 More Info >	£3.38
39	Backing Plate - Blade Beam 411-322-710 More Info >	£16.11
40	Beam - Std - Blade Mounting 411-322-760 More Info >	£28.03
41	Clamp Plate - Blade Beam 411-322-800 More Info >	£5.28
42	Blade - Spindle - Flat 411-160-700 More Info >	£7.42
42	Blade - Fling-Tip Blade - Classic (16070/U) i See notes section for usage notes on this part 411-160-702 More Info >	£7.42
43	Blade Bolt - D-Bolt With M10 Nyloc Nut - Classic Blade Mounting 411-322-100 More Info >	£3.28
44	Nut - Nyloc 307-210-053 More Info >	£0.53
