750 - X-WAM S1 1040 - Deck Assembly

X-WAM S1 1040

Grouped product items
No.	Product Name	Price
1	Body Weldment - Pegasus S4 237 RH 502-000-109 More Info >	Price on Request
4	Cutting System Assembly 237 503-000-008 More Info >	£2,183.49
5	Wash Panel - RH (ABT) 410-000-232 More Info >	£19.01
6	Nut - Nyloc M12 - Trimax Specification - 307-212-053 More Info >	£0.53
7	Washer - Spring M12 - Trimax Specification - 308-120-043 More Info >	£0.33
8	Nut - Plain M12 - Trimax Specification - 307-212-013 More Info >	£0.80
9	Pad 417-153-140 More Info >	£17.80
10	Nut - Nyloc 307-208-056 More Info >	£0.53
11	Washer - Flat 308-080-016 More Info >	£0.33
12	Bolt - Hex Head - M8 x 25 - Trimax Specification 301-208-253 More Info >	£0.65
13	Washer - Crinkle 450-000-116 More Info >	£1.11
14	Buffer Tower Weldment 418-000-550 More Info >	£203.06
15	Bolt - Hex Head - M12 x 35 - Trimax Specification 301-212-353 More Info >	£1.38
16	Slide Pad - Buffer Tower 402-000-095 More Info >	£13.88
17	Countersunk Screw - Socket Head - M6 x 16 - Trimax Specification 302-206-165 More Info >	£0.58
18	Nut - Nyloc 307-206-053 More Info >	£0.33
19	Cover Weldment - Transmission - RH Outer 237 410-000-300 More Info >	£230.60
20	Cover Weldment - Transmission - LH 178/237/290 410-000-296 More Info >	£159.60
21	Adjustable Catch - Covers 423-080-220 More Info >	£13.05
22	Blind Rivet 213-443-250 More Info >	£0.28
23	Safety Flap 237 410-000-097 More Info >	£133.71
25	Clamp Strip - Safety Flap 237 410-841-220 More Info >	£60.08
26	Bolt - Hex Head - M6 x 20 - Trimax Specification 301-206-203 More Info >	£0.43
